9. LABELED INSTRUMENT PHOTOS
FIGURE 9-1: Top view of Model 202 Ozone Monitor with cover removed.
Ozone Scrubber
Printed Circuit Board
Scrubber Filter
Solenoid Valve
Air Inlet
