3.2 Intercom Control as Viewed by External
User
Quick Dialling Buttons
By pushing a quick dialling button on the basic unit you can call to positions 1, 3...6 of
the telephone directory (depending on the model type). With extending modules you
can use up to 54 quick dialling options.
By pushing a quick dialling button you call the telephone number assigned to the
selected telephone directory position. A call set-up is signalled by a long
discontinuous tone or any other tone as defined in the attached PBX configuration.
By re-pushing the same button during calling or setting up you can hang up, hang up
and call to another telephone number, or activate nothing as defined in the Intercom
Configuration / Hardware / Keyboard subsection of Configuration Manual.
You can also hang up the call any time by pushing if the button is Hang-up by #
enabled; refer to Intercom Configuration / Hardware / Keyboard subsection of
Configuration Manual.
Calling to Phone Book Position
The telephone directory may contain up to 1999 pre-programmed 2N Helios IP Vario
®
positions. You can use the quick dialling buttons for positions 1 to 54 only. To retrieve
the remaining positions, use the numeric keypad if is Dial Users by Phonebook Position
enabled; refer to the Intercom Configuration / Hardware / Keyboard subsection of
Configuration Manual.
Procedure:
Enter the position number using the numeric keypad (e.g. 05, 15, 200, 1759 – two
digits at least and four digits at most) and push for confirmation.
You can also hang up the call any time by pushing if the Hang-up by #
button is enabled; refer to Intercom Configuration / Hardware / Keyboard
subsection of Configuration Manual.
Calling to User-Defined Telephone Number
If the (refer to the Intercom Configuration / Hardware / Telephone function enable
Keyboard subsection of Configuration Manual) is selected, you can call the user-
defined telephone number using the numeric keypad.2N Helios IP Vario
®
