External Power Supply Connection
2N
®
IP Forcecan be fed either from an external12 V ±15 % / 2 A DCpower
supply or from the LAN equipped with the PoE 802.3af supporting network
elements.

External Power Supply
An external 12V power supply is connected to terminal block X19. Use a 12V
±15% DC power source dimensioned to current intake of 2A at least (Part
No. 91341481E) to ensure a reliable function of your device.

PoE Supply
2N
®
IP Forceis compatible with the PoE 802.3af (Class 0–12.95W)
technology and can be supplied directly from the LAN via compatible
network elements. If your LAN in incompatible, insert the PoE injector, Part
No. 91378100E/US, between
2N
®
IP Forceand the nearest network element.
Electric Lock Connection
2N
®
IP Forceis equipped with an electrically isolated relay switch with NO
and NC contacts (terminal block X17,max. 30 V / 1 A AC/DC) and9 up to 13 V
DCdepending on power supply (PoE: 9 V; adaptor: power supply voltage
minus 1V), max 600mAswitched output (terminal block X18), to which a
standard electric lock or another compatible electrical appliance can be
connected.
• We recommend the use of a shielded SSTP Ethernet cable.
•
Note
Devices with PCB version 555v3 and higher provides independent control of 12V switched output
(terminal block X18) and relay switch (terminal block X17). Devices with PCB version 555v2 have
both outputs switched simultaneously.

