Installation manual 2N® IP Force
•
•
•
•
Reset Button
Located among the main unit connectors, the Reset button helps you reset
the factory default values, restart the device, find the device IP address and
switch the static/dynamic mode.
IP Address Finding
Follow the instructions below toidentify thecurrent IP address:
Press and hold the RESET button.
Wait until the red and green LEDs go on simultaneously on the device and the acoustic signal can be
heard (approx. 15–35 s).
Release the RESET button.
The device automatically announces the current IP address.
Warning
When you connect a device containing a coil, such as a relay or an
electromagnetic lock, it is necessary to protect the intercom against
voltage peak while switching off the induction load. For this way of
protection we recommend a diode 1 A / 1000 V (e.g., 1N4007, 1N5407,
1N5408) connected antiparallel to the device.
