2N IP Force - Page 109

2N TELEKOMUNIKACE a.s., www.2n.cz 109/117
Active switch output: 9 up to 13 V DC depending on power supply (PoE: 9 V;
adaptor: power supply voltage minus 1 V), max 600 mA
RFID card reader
Optional
Includes besides card reader itself: Wiegand interface, tamper switch,
active output, relay, two inputs
Supported cards on 125 kHz version, Part No. 9151011
EM4100, EM4102, HID Prox
Supported cards on 13.56 MHz version, Part No. 9151016 (only card serial number
is read)
ISO/IEC 14443A
Mifare Classic 1k & 4k, DESFire EV1, Mini, Plus S&X, Ultralight,
Ultralight C
ISO/IEC 14443B
CEPAS, HID iCLASS
JIS X 6319
Felica
Supported cards on 13.56 MHz NFC version, Part No. 9151017 (only card serial
number is read)
ISO/IEC 14443A
Mifare Classic 1k & 4k, DESFire EV1, Mini, Plus S&X, Ultralight,
Ultralight C
ISO/IEC 14443B
CEPAS, HID iCLASS
JIS X 6319
Felica
ISO/IEC 18092
SmartPhone with NFC/HCE support, since Android version 4.3
