2.4 Extending Module Connection
2N IP Force
®
allows to connect following extending modules:
Additional Switch
Internal RFID Card Reader 125 kHz
Internal RFID Card Reader 13.56 MHz
Internal secured RFID Card Reader 13.56 MHz
Security Relay
Wiegand Isolator
Induction Loop
Additional Switch
The (Part No. 9151010) is used for extending the number of outputs. Additional Switch
This extending module is intended for mounting into the main unit and is 2N IP Force
®
compatible with the basic units with Part No. 915110xxxxx. If the Additional Switch is
installed, it is not possible to install Internal RFID Card Reader.
Function:
The Additional Switch adds two additional switches and a tamper switch 2N IP Force
®
to the basic unit. The purpose of the tamper switch is to signal any 2N IP Force
®
unauthorised opening of the intercom (to prevent a theft, e.g.). It is recommended to
use the tamper switch.
Tip
FAQ: Tamper switch - How to install it into the 2N IP Force
®
Specifications:
