X10 – Buttons 1 through 4
X11 – LAN
X12 – Servicing connector
X13 – Keypad module
X15 – Left-hand microphone
X16 – Right-hand microphone
X17 – Relay NO and NC contact max. 30 V / 1 A AC/DC
X18 – Switched output 9 up to 13 V DC depending on power supply (PoE: 9 V;
adaptor: power supply voltage minus 1 V), max 700 mA
X19 – Power input 12 V ±15 % / 2 A DC
LED1/2 – System status indicators
LED3 – LAN connection activity indicator
2N IP Force
®
Connectors, PCB Version 555v2
