Caution
In case of resetting the factory default settings on a device with a
version of firmware 2.18 or higher it is necessary to reprogram the
using the instructions from section .2N Security Relay
®
2.4
IP Address Finding
Follow the instructions below to :identify the current IP address
Press and hold the RESET button.
Wait until the red and green LEDs on the device come on simultaneously
(approx. 20 s).
Release the RESET button.
The device announces the current IP address via the loudspeaker connected
automatically.
Static IP Address Setting
Follow the instructions below to switch on the mode (DHCP OFF):Static IP address
Press and hold the REST button.
Wait until the red and green LEDs on the device come on simultaneously
(approx. 20 s).
Wait until the red LED goes off (approx. 5 s).
Release the RESET button.
The following network parameters will be set after restart:
IP address: 192.168.1.100
Network mask: 255.255.255.0
Default gateway: 192.168.1.1
