2N IP Force User Manual

2N TELEKOMUNIKACE a.s., www.2n.cz 6/117
2N IP Force
®
is equipped with an electric lock switch. You can control the switch
using a numerical keypad or, during a call, using any telephone set. An additional
switch module can be installed if necessary. A wide range of settings allow for a
variety of applications.
2N IP Force
®
can also be provided with RFID card reader modules.
2N IP Force
®
is very easy to install. All you have to do is connect the system into your
LAN via a network cable and feed it from a 12 V power supply or your PoE supporting
LAN.
Configure using your PC via any web browser. Use the2N IP Force
®
to manage extensive systems easily and 2N Access Commander
®
2N IP Force
®
quickly.
Advantages of Use
Uncompromising Antivandal design
High coverage level – up to class IP69K
Variable mounting options (brick/plasterboard flush mounting, surface
mounting)
Sensitive microphone and powerful loudspeaker
Bidirectional communication – acoustic echo cancelling
Integrated colour camera with wide-angle lens
Optional dial buttons including name tags and backlight
Optional numerical keypad with backlight
Integrated electronic lock switches with wide setting options
Optional integrated RFID card reader module
LAN (PoE) or external 12 V power supply
Configuration via web interface or dedicated PC application
SIP 2.0 support
Up to 1999 telephone directory positions
Up to 20 user time profiles
Video codecs (H.263, H.263+, H.264, MPEG-4, JPEG)
Audio codecs (G.711, G.729, G.722, L16/16kHz)
HTTP server for configuration
SNTP client for time synchronisation with server
RTSP server for video streaming
SMTP client for e-mail sending
TFTP client for automatic configuration and firmware update

2N IP Force Specifications

General

Buttons quantity	4
Connectivity technology	Wired
Speakerphone	Yes
Video codecs	H.263+, H.263, H.264, MJPEG
Number of buttons	4 buttons
Number of displays supported	-
Voice codecs	G.711, G.722, G.729
Speaker power	10 W
Viewing angle, vertical	109 °
Maximum image resolution	640 x 480 pixels
Viewing angle, horizontal	135 °
Product color	Gray
International Protection (IP) code	IP69K
Indoor unit power type	DC
AC adapter output current	2 A
AC adapter output voltage	12 V
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3af
Supported network protocols	SIP2.0, DHCP opt. 66, SMTP, 802.1x, RTSP, RTP, TFTP, HTTP, HTTPS, Syslog, ONVIF
Display diagonal	- \
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-40 - 55 °C
Operating relative humidity (H-H)	10 - 95 %

Weight and Dimensions

Depth	83 mm
Width	109 mm
Height	217 mm
