3Com 3CRWX375075A - Wireless LAN Managed Access Point 3750 User Manual

6
Cable Requirement
The Ethernet ports on the access point cannot accept a Category 5 cable that has an uneven sheath
such as the one shown in the figure below. The RJ-45 connector on the cable will not seat properly in
the receptacle on the access point. Use a Category 5 cable with an even sheath instead.
Suspended Ceiling — Flush Ceiling Tiles
This procedure applies to T-bars that are 23.9 mm (15/16 inches) wide. For a 14.2-mm (9/16-inch) or
15.9-mm (5/8-inch) T-bar, go to
“Suspended Ceiling Installation — Drop Ceiling Tiles” on page 8.
1 Use the mounting template to cut a hole for the Category 5 cable.
2 Remove the mounting bracket from the access point.
U
neven sheath
Mounting
bracket
Mounting
template
Mobility
point
T
M
AP3750 access point
Mounting template Mounting bracket
840-9502-0011
840
-
9502
-
0008
10015414-AA_AP3750_QSG.fm Page 6 Tuesday, July 25, 2006 1:59 PM

3Com 3CRWX375075A - Wireless LAN Managed Access Point 3750 Specifications

General

Brand	3Com
Model	3CRWX375075A - Wireless LAN Managed Access Point 3750
Category	Wireless Access Point
Language	English
