3Com 5500-EI - Page 23

Switch 5500 — Rear View Detail 23
Figure 13 2-port 10 Gbps XFP module
Tabl e 6 lists the available XFP transceivers.
Table 6 XFP transceivers supported by 2-port 10 Gbps XFP module
Notes:
■ The type of 10 Gbps XFP module may be different from those listed
above. For the most up-to-date information, refer to www.3com.com.
■ For XFP transceiver specifications, refer to 3Com’s Web site at
www.3Com.com.
1-port 10 Gbps XENPAK module
This module, shown in Figure 14, provides one 10 Gbps XENPAK
transceiver port.
(1) Module power LED (2) 10 Gbps XFP optical
ports
(3) 10 Gbps XFP optical ports
Type Model
XFP transceivers 3CXFP90 10GBASE-LRM
3CXFP92 10GBASE-LR
3CXFP94 10GBASE-SR
3CXFP95 10GBASE-CX4
3CXFP96 10GBASE-ER
