60 CHAPTER 4: CONFIGURING THE SWITCH
Summary
Use the Summary tab to display Status, Edged
Port, Link Type, Path Cost, State, or Port Priority
for all the ports.
Figure 46 Spanning Tree Summary Screen
Detail
Use the Detail tab to display detailed spanning
tree information for a port.
Figure 47 Spanning Tree Detail Screen
Setup
Use the Setup tab to configure the spanning
tree settings for each port. The following
options are available:
■ Status – Enables and disables spanning tree
for the port.
■ Edged Port – Enables and disables edged
port for the port.
