3Com Baseline Switch 2900 Series User Manual

3-2
Figure 3-2 Two-holed mounting bracket
(1) Screw hole used to fix the mounting bracket
to the rack (with an M6 screw)
(2) Screw hole used to fix the switch to the
mounting bracket
Figure 3-3 Four-holed mounting bracket
(1) Screw hole used to fix the mounting bracket
to the rack (with an M6 screw)
(2) Screw hole used to fix the switch to the
mounting bracket
Attaching the Mounting Brackets to a Switch
The installation of actual mounting brackets vary with devices.
