Pin-Outs 75
Table 8 Pin Assignments
Pin Number 10/100 1000
Ports confi
ured as MDIX
1 Receive Data + Bidirectional Data B+
2 Receive Data • Bidirectional Data B•
3 Transmit Data + Bidirectional Data A+
4 Not assi
ned Bidirectional Data A•
5 Not assi
ned Bidirectional Data D+
6 Transmit Data • Bidirectional Data D•
7 Not assi
ned Bidirectional Data C+
8 Not assi
ned Bidirectional Data C•
