RJ-45 Pin Assignments
57
Table 12 Pin assignments
Pin Number 10/100BASE-T 1000BASE-T
Ports configured as MDIX
1 Receive Data + Bidirectional Data B+
2 Receive Data - Bidirectional Data B-
3 Transmit Data + Bidirectional Data A+
4 Not assigned Bidirectional Data D+
5 Not assigned Bidirectional Data D-
6 Transmit Data - Bidirectional Data A-
7 Not assigned Bidirectional Data C+
8 Not assigned Bidirectional Data C-
