Serial Connectors and Flex-WAN Cables 57
Table 20 RS-530 DTE Cable Pinouts
Flex-WAN Connector RS-530 DTE Connector
Signal Pin Direction Pin Signal
CTS/RTS+ 1 ← 5 CTS+
CTS/RTS- 2 ← 13 CTS-
DSR/DTR+ 3 ← 6 DSR+
DSR/DTR- 4 ← 22 DSR-
DCD/DCD+ 5 ← 8 DCD+
DCD/DCD- 5 ← 10 DCD-
DTR/DSR+ 7 → 20 DTR+
DTR/DSR- 8 → 23 DTR-
RTS/CTS+ 9 → 4 RTS+
RTS/CTS- 10 → 19 RTS-
TxD/RxD+ 11 → 2 TxD+
TxD/RxD- 12 → 14 TxD-
TxCE/TxC+ 13 → 24 TxCE+
TxCE/TxC- 14 → 11 TxCE-
TxC/RxC- 23 ← 12 TxC-
TxC/RxC+ 24 ← 15 TxC+
RxC/TxCE- 25 ← 9 RxC-
RxC/TxCE+ 26 ← 17 RxC+
RxD/TxD- 27 ← 16 RxD-
RxD/TxD+ 28 ← 3 RxD+
LL/DCD 44 ← 18 LL
Circuit Ground 45 - 7 Circuit Ground
Shield Ground 46 Cable Shield 1 Shield Ground
Shorting Group 1 47
48
49
- - -
HWBook Page 57 Friday, June 19, 1998 3:42 PM
