3M 900 Series Overhead Projector
Illustrated Parts Breakdown
14
 3M 1996
Section 7
BASE ASSEMBLY
Item No. Part Number Description Qty
1A 78-8064-1788-3 MIRROR ASSEMBLY, Body, M900 before S/N 805302, (See Note 1) 1. . . . . . . . . . . . . . . . . . . . . .
1B 78-8073-6954-7 MIRROR ASSEMBLY, Body,. . . . . . . . . . . . .
M900 after S/N 805302 and European-built M900 After S/N 9.000.001 1. . . . .
1C 78-8073-7252-5 MIRROR ASSEMBLY, Body (Model M955 only) 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 26-1008-3329-7 STAND OFF/SPACER 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 26-1002-6213-3 SCREW, M4, Special 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4A 78-8073-6955-4 BASE, Charcoal Brown 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4B 78-8073-7254-1 BASE ASSEMBLY (U.S. and Canada M955 only) 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4C 78-8073-7289-7 BASE ASSEMBLY (Outside U.S. and Canada M955 only) 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 78-8064-1656-2 CATCH, Post 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 78-8079-8890-8 CRADLE, Post 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7 78-6969-7794-7 FOOT KIT (4 feet and screws) 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8A 78-8064-1464-1 BAFFLE (U.S. and Canada M955 only) 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8B 78-8073-7288-9 BAFFLE (Outside U.S. and Canada M955 only) (Does not include Baffle Plate) 1. . . . . . . . . . . . . .
9 78-8073-7306-9 PLATE, Baffle (Use with 78-8073-7288-9 only) 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10 26-1007-5427-9 SCREW, Pan Head, Phillips, 6-19 X 3/8” 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11 78-8064-1518-4 HOLDER, Body Mirror (Use with 78-8064-1788-3 Mirror Assembly) 1. . . . . . . . . . . . . . . . . . . . . .
12 26-1002-4948-6 SCREW, Plastite, 6-19 X 5/16” 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13 26-1008-0070-0 NUT, Push-on, .250 dia. 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Note 1. The old style Body Mirror Assembly (78-8064-1788-3) will fit in the newer 900’s (after S/N 805302), however,
the new style Body Mirror (78-8073-6954-7) will not fit in the 900s before S/N 805302.
