3M 900 Series - Section 1 SYSTEM OVERVIEW

3M 900 Series Overhead Projector
Illustrated Parts Breakdown
3
 3M 1996
Section 1
SYSTEM OVERVIEW
Projection Head Assemblies
(See Sections 2 and 3)
Arm, Post and Focus Assembly
(See Section 4)
Top Cover Assembly
(See Section 5)
Lamp Housing Assemblies
(See Sections 8, 9, and 10)
Base Assembly
(See Section 7)
Fresnel and Stage Assembly
(See Section 6)
Roller Attachment (Not Shown)
(See Section 11)
