10 3M™ Dual-Touch Chassis Displays User Guide
3M Touch Systems, Inc. Proprietary Information – TSD-42846A
CHAPTER 2
Setting Up Your Dual-Touch Chassis Display
This chapter describes how to set up your 3M Touch Systems Dual-Touch Chassis
Display. You need to complete the following tasks:
• Unpack the components
• Connect the video cable, touch display USB cables, and power cable
• Power on the display and test your setup
• If you are not running Windows® 7 (or Tablet PC), install software from the
enclosed CD.
Unpacking Your Touch Display
Carefully unpack the carton and inspect the contents. Your Dual-Touch Chassis Display
includes the following cables and accessories:
• USB communication cable
• VGA video cables
• Power cable and DC power supply
• Touch documentation and driver CD
• Hardware kit -- 2 mounting brackets and (4) M4x6 screws
USB cable
DC power supply
Power cable
Touch driver CD
VGA cable
Quick Start Guide
2 L-Brackets
4 (M4X6) Screws
