3M™ Dual-Touch Chassis Displays User Guide 5
3M Touch Systems, Inc. Proprietary Information – TSD-42846A
19” – 376.3mm x 301.1mm
• Horizontal frequency range:
15 inch display -- 31.47 ~ 60 kHz
17 & 19 inch display -- 31.47 ~ 80 kHz
• Vertical frequency range:
15, 17, & 19 inch displays -- 56 ~ 75 Hz high refresh rate
• Pixel pitch
15 inch display -- 0.297mm x 0.297mm
17 inch display -- 0.264mm x 0.264mm
19 inch display -- 0.294mm x 0.294mm
• Auto adjustment function
• Multilingual OSD user controls
• VESA mount
15 inch display -- 75mm x 75mm
17 & 19 inch display -- 75mm x 75mm or 100mm x 100mm
• Bracket or VESA mount
• Projected capacitive touch screen with USB controller
Touch Screen for Dual-Touch Displays
• Projected capacitive touch screen for finger input only
• Surface: Anti-glare treatment
• Interface: USB controller
• Transmittance: 90±5%
• HID: Windows® 7
• Driver: VISTA, XP, 2000, CE, XP Embedded, Linux, Apple® Mac OS
Important Safety Information
Read and understand all safety information before using this product. Follow all
instructions marked on the product and described in this document. Pay close attention to
the following installation warnings and safety precautions.
Intended Use
The 3M Dual-Touch Display was designed for touch input and tested to replace an
existing display. These displays are intended for indoor use only and are not designed
for use in hazardous locations.
Explanation of Signal Word Consequences
DANGER: Indicates a potentially hazardous situation, which, if not avoided,
will cause death or serious injury and/or property damage.
WARNING: Indicates a potentially hazardous situation, which, if not avoided,
could cause death or serious injury and/or property damage.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided,
may cause minor or moderate injury and/or property damage.
