3M™ Dual-Touch Chassis Displays User Guide 15
3M Touch Systems, Inc. Proprietary Information – TSD-42846A
4. With the OSD menu on screen, press the Menu button to return main menu or exit
OSD.
5. The OSD menu will automatically close if you have left it idle for a pre-set time.
6. To Lock the OSD / Power menu buttons, please follow the instructions below.
(Please note: the monitor has to be turned ON with a valid signal pre-set).
a. Press Menu key, the OSD menu will appear.
b. Press and hold the Menu key again with the OSD menu on the screen, the OSD
menu will disappear. Then press the Power key once while the menu key is still
being pressed. The Lock/Unlock menu will appear for 3 seconds.
c. Use the Enter key to select OSD or Power setting then set at Lock by pushing
the Up or Down button.
d. When the Up or Down button is released, the previous setting will be saved and
exit the Lock/Unlock menu automatically.
7. To Unlock the OSD / Power menu buttons, please follow the instructions below.
Please note: the monitor has to be turned ON with a valid signal pre-set.
a. Press and hold the Menu key then press the Power key simultaneously and the
Lock/Unlock menu will appear for 3 seconds.
b. Use the Enter key to select OSD or Power setting then set at Unlock by pushing
the Up or Down button.
c. When the Up or Down button is released, the previous setting will be saved and
exit the Lock/Unlock menu automatically.
Note:
When the OSD Lock Function is selected, this indicates that all the buttons except
Power are now disabled.
When the Power Lock function is selected, this indicates that the power key is
disabled; user cannot turn off the monitor using the Power key.
On-Screen Display Menus
Item Content
Contrast The monitor luminance level control.
Brightness The monitor backlight level control.
Auto Adjust Fine-tune the image to full screen automatically.
Left/Right Moving screen image horizontal position to left or right.
Up/Down Moving screen image vertical position to up or down.
Horizontal size The screen image horizontal dot clock adjustment.
Fine The screen image pixel phase adjustment.
OSD Left/Right Moving OSD menu horizontal position to left or right.
OSD Up/Down Moving OSD menu vertical position to up or down.
OSD Time out OSD auto-disappear time selection.
OSD Language OSD menu language selection.
(English, French, Japanese, German, Spanish, Italian, Traditional
Chinese and Simplified Chinese)
Factory Reset Factory default value restored.
RGB Color temperature selection (9300K, 6500K, 5500K, 7500K, User)
