5. Select a channel for each of the base stations. (See page 14 for the channel selection procedure.) After you
select the channel, press the RESET SWITCH on the base station circuit boards to “read” the selection into the
microprocessor.
6. Re–program the headsets as instructed on page 15.
1. Check the operation of each of the systems. Note that the alert tone for the Lane 1 system headsets is a
single repeating “beep” while the alert tone for the Lane 2 system headsets is a double repeating “beep.”
Cross-Lane System Installation
Description
The Cross-Lane System is designed for facilities that have two menu signs. It consists of two Wireless Base Stations that are
connected to a Cross–Lane Module. A Cross–Lane Module is a five–pole switch that allows the two systems to be separated
during hours of peak activity. The Cross-Lane System can be used with C760, C860, C960, C1025, and C1060 headsets. The
C760 headset may require additional equipment.
A Cross–Lane Module can be useful if the manager wishes to operate each lane with a separate crew during
periods of peak activity. This is accomplished by turning the Cross–Lane switch OFF. By pressing the T1 button
on any headset, the operator can communicate with a customer at menu sign 1. By pressing the T2 button on any
headset, another operator can communicate with a customer at menu sign 2. When the Cross–Lane Module is
OFF, the operator will only hear the vehicle detector alert from the menu sign with which he or she last talked.
During periods of lower activity, the Cross–Lane Module is turned ON, allowing one headset order–taker to operate both
lanes. When the Cross–Lane Module is turned ON, the operator will always hear vehicle detector alerts from both menu signs.
A single alert indicates a vehicle is a menu sign 1, while a double alert indicates a vehicle is at menu sign 2.
Additional Material Required
• A sufficient length of two-conductor 20 AWG twisted pair shielded audio cable (not supplied) for connecting the Cross-
Lane Module to the two base stations.
• Applicable screws/fasteners (not supplied) for mounting the Cross-Lane Module.
Installation
Notes: Both base stations must be set to the same channel number and different lane numbers.
Base station models C921 and earlier must be mounted at least
25 feet apart. Base station models C922
may be mounted as close as 2 feet apart. Test the system prior to installation by placing the base stations
in the desired locations. Set Jumpers and program the headsets. Insure that the talk L.E.D. on the proper
base station lights when the appropriate (T1 and T2) button on the headset is pressed.
