3M DBI SALA Variable Davit - Page 5

5
9
PP
4
3
2
1
A4
A3
A2
A1
A1
X
Y
X
PP1 PP2 PP3 PP4
A2, A3
Min
12.0 in.
(30.5 cm)
14.0 in.
(35.6 cm)
16.5 in.
(41.9 cm)
19.5 in.
(49.5 cm)
Max
16.0 in.
(40.6 cm)
18.5 in.
(47.0 cm)
22.0 in.
(55.9 cm)
26.0 in.
(66.0 cm)
A4
Min
13.0 in.
(33.0 cm)
15.0 in.
(38.1 cm)
17.5 in.
(44.5 cm)
20.5 in.
(52.0 cm)
Max
18.5 in.
(47.0 cm)
21.0 in.
(53.3 cm)
25.0 in.
(63.5 cm)
28.5 in.
(72.4 cm)
A#
PP1 PP2 PP3 PP4
A1*
5,000 lbf
(22.2 kN)
5,000 lbf
(22.2 kN)
5,000 lbf
(22.2 kN)
5,000 lbf
(22.2 kN)
A2
3,600 lbf
(16.0 kN)
3,000 lbf
(13.0 kN)
2,700 lbf
(12.0 kN)
2,250 lbf
(10.0 kN)
A3
1,800 lbf
(8.0 kN)
1,800 lbf
(8.0 kN)
1,800 lbf
(8.0 kN)
1,800 lbf
(8.0 kN)
A4
1,800 lbf
(8.0 kN)
1,800 lbf
(8.0 kN)
1,800 lbf
(8.0 kN)
1,800 lbf
(8.0 kN)
* - Y ≤ 15.0 in. (38.0 cm)
10
BPP PP
1 1
2 2, 1
3 3, 2, 1
4 4, 3, 2, 1
1234
4321
BPP
BPP
