3M LAD-SAF Installation Instructions

11
Table 2 – Component

Standards
Figure
Capacity
(lbs/kg)
Minimum
User 
(lbs/kg)
No. Users
Activation Force
(lbs/kN)
Max deployment

Minimum
Breaking

(lbs/kN)
Weigt
(lbs/kg)
Operating
temp range
(°F/°C)
Component
Item
Number
Material
Part
Code
Max Min
System - L1* 6116632
304
Stainless
Steel
L1
ANSI, AUS,
CE, CSA,
OSHA
2 310/140 2 3,600/16 20/9.1 140/60 -40/-40
System - L2* 6116631
Galvanised
Steel
L2
ANSI, AUS,
CE, CSA,
OSHA
2 310/140 2 3,600/16 20/9.1 140/60 -40/-40
System - L3* 6116633
Galvanised
Steel
L3
ANSI, AUS,
CE, CSA,
OSHA
3 310/140 4 4,560/20.27 24/10.9 140/60 -40/-40
System - M1* 6116638
304
Stainless
Steel
M1
ANSI, AUS,
CE, CSA,
OSHA
4 310/140 4** 4,560/20.27 9/4.1 140/60 -40/-40
System - M2* 6116634
Galvanised
Steel
M2
ANSI, AUS,
CE, CSA,
OSHA
4 310/140 4** 4,560/20.27 9/4.1 140/60 -40/-40
System - W1 6116635
Galvanised
Steel
W1
ANSI, AUS,
CE, CSA,
OSHA
7 310/140 2 3,600/16 14/6.4 140/60 -40/-40
System - CE1* 6116636
Galvanised
Steel
CE1
ANSI, AUS,
CE, CSA,
OSHA
8 310/140 2 3,600/16 46/21 140/60 -40/-40
System - T1* 6116618
Galvanised
Steel
T1
ANSI,
OSHA
9 310/140 4 4,560/20.27 40/18.2 140/60 -40/-40
Lad-Saf X2 6160030
Stainless
Steel
ANSI, CE,
CSA, OSHA
13 310/140 88/40 1 450/2 4.0/102 3,600/16 2.1/1 140/60 -40/-40
Lad-Saf X2 6160047
Stainless
Steel
ANSI, CE,
CSA, OSHA
14 310/140 88/40 1 450/2 4.0/102 3,600/16 2.1/1 140/60 -40/-40
Lad-Saf X3 6160054
Stainless
Steel
ANSI, CE,
CSA, OSHA
15 310/140 88/40 1 450/2 4.0/102 3,600/16 2.1/1 140/60 -40/-40
Lad-Saf X3+ 6160052
Stainless
Steel
AUS, CE
16 310/140 88/40 1 450/2 4.0/102 3,600/16 2.1/1 140/60 -40/-40
Lad-Saf X3+ 6160065
Stainless
Steel
AUS, CE
17 310/140 88/40 1 450/2 4.0/102 3,600/16 2.1/1 140/60 -40/-40
Cable - 3/8"
(9.5mm) 1x7
6104XXX /
CE
6134XXX(m)
Galvanised
Steel
15,400/68.4
0.27/ft-
0.41/m
140/60 -40/-40
Cable - 3/8"
(9.5mm) 1x7
6105XXX /
CE
6135XXX(m)
Stainless
Steel
18,000/80
0.27/ft-
0.41/m
140/60 -40/-40
Cable - 3/8"
(9.5mm) 7x19
6106XXX /
CE
6136XXX(m)
Galvanised
Steel
14,400/64
0.27/ft-
0.41/m
140/60 -40/-40
Cable - 3/8"
(9.5mm) 7x19
6107XXX /
CE
6137XXX(m)
Stainless
Steel
12,000/53.3
0.27/ft-
0.41/m
140/60 -40/-40
*System - Single Point Anchor minimum breaking strength 3,600 lbs (16kN).
** Number of users limited to 1 when used in conjunction with SO-4 & SO-5. See Figure 5.

on cover
1 Installation instructions Figure 1 A Top Bracket
2
Lad-Saf
™
Flexible Cable Safety Systems B Sleeve
3
Standards C Cable
4 Number of notied body that performed CE test. D RFID Tag
5 Number of notied body checking the manufacture of this PPE. E Cable Guide
6
Number of users. F Bottom Bracket
7
User weight is 88 - 310 lbs (40 - 140kg) including tools, other
equipment and clothing.
