3M LAD-SAF Installation Instructions

10
Table 1 –
Component Descriptions
 Figure Description
Stando
Bracket
SO-1 6100705
5
Flex Top/Btm Stando, 2” OD 24.25” Pole Centers
SO-2 6100710 Flex Stando, Pole, SS
SO-3
6100675 Flex Cable Guide Stando, 2” OD Pole
6100677 Flex Cable Guide Stando, 2-1/2” OD Pole
6100679 Flex Cable Guide Stando, 3” OD Pole
6100680 Flex Cable Guide Stando, 3-1/2” OD Pole
6100681 Flex Cable Guide Stando, 4” OD Pole
6100682 Flex Cable Guide Stando, 4-1/4” OD Pole
SO-4
6100636 Angle Iron Stando 3", 90 Deg, Top & Bottom, Galv
6100642 Angle Iron Stando 8", 90 Deg, Top & Bottom, Galv
SO-5
6100651 Flex Top/Btm Stando, 2-3/8” OD Pole
6100652 Flex Top/Btm Stando, 2-1/2” Dia Pole
6100654 Flex Top/Btm Stando, 3” OD Pole
SO-6
6100621 Angle Iron Stando 3", 90 Deg, Cable Guide, Galv
6100627 Angle Iron Stando 6", 90 Deg, Cable Guide, Galv
6100629 Angle Iron Stando 8", 90 Deg, Cable Guide, Galv
6100635
Angle Iron Stando 2", 90 Deg, Top & Bottom, SS
SO-7 6100386 Flex Cable Guide Stando, Steel
SO-8 6100232 Flex Stando, 5-10" Pole,
SO-9 6100230 Flex Stando
Cable
Guides
Typical

Structure

Structure

CG-2 6100140
12
Flex Cable Guide, SS Wood pole NA
NA
CG-3 6100400 Flex Cable Guide Assy, Galv Standard < 1-1/8 in
Round/Square
CG-3 6100401 Flex Cable Guide Assy, SS
LEB &
Telescoping
<1-1/8 in
Round/Square
CG-3
6100410 Flex Cable Guide, Galv Standard <1 in
Round/Square
CG-5 6100427 Flex Cable Guide Assy, SS Standard 1-5/8x1
Round/Square
CG-3
6100440 Flex Cable Guide, SS Standard <1 in
Round/Square
CG-3
6100450 Flex Cable Guide, SS
LEB &
Telescoping
<1 in
Round/Square
CG-6
6100454 Flex Cable Guide Assy, SS Standard 1x3/4 in
Angle
CG-5 6100457 Flex Cable Guide Assy, SS Standard <1 in
Round/Square
CG-7
6100500 Flex Cable Guide, Galv, L Monopole 5-3/4 in Long
NA
CG-9
6100505 Flex Cable Guide Assy, SS, L Monopole 5-3/4 in Long
NA
CG-9
6100512 Flex Cable Guide, SS, L Monopole 5-3/4 in Long
NA
CG-9
6100513 Flex Cable Guide, SS, L Standard <1-5/8 in
Round/Square
CG-9
6100515 Flex Cable Guide Assy, Galv, L Monopole 5-3/4 in Long
NA
CG-9 6100519 Flex Cable Guide, SS, L Standard <2-1/8 in
Round/Square
CG-9 6100522 Flex Cable Guide Assy, Galv, L Monopole 5-3/4 in Long
NA
CG-7 6100527 Flex Cable Guide Assy, SS, L Monopole 1x1 in
Angle
CG-14 6100530 Flex Cable Guide Assy, Galv, Latch Standard <1 in
Round/Square
CG-14 6100531 Flex Cable Guide, Galv, Latch Standard <1 in
Round/Square
