9
;
Prior to installation and use of this equipment, record the product identication information from the ID label in the
Installation Checklist at the back of this manual.
PRODUCT DESCRIPTION:
Figure 1 illustrates the Lad-Saf
®
Flexible Cable Safety System. Figures 2 through 19 illustrate components of the Lad-Saf
®
Flexible Cable Safety System. See Table 1 for system component descriptions. See Table 2 for system component specications.
Table 1 –
Component Descriptions
Item
Number
Figure Description
Systems L1 and L2 6116632
6116631
2 Used on standard rung attachments. Additional feature (“A” in Figure 2) serves as a single
point anchor for a single user attachment. Minimum breaking strength is 3,600 lbs (16kN).
Conforms to EN795:2012 Type A, OSHA 1926.502, 1910.140, AS/NZS 5532.
L1 and L2 Systems will t rung types and spacing listed below.
System L3 6116633 3 Used on standard rung attachments. Additional feature (“A” in Figure 3) serves as a single
point anchor for a single user attachment. Minimum breaking strength is 3,600 lbs (16kN).
Conforms to EN795:2012 Type A, OSHA 1926.502, 1910.140, AS/NZS 5532.
L3 System will t rung types and spacing listed below.
Systems M1 and M2 6116638
6116634
4 Used on standard monopoles or in combination with stando supports. Mounting holes
spaced 4” (101mm) on center. Additional feature (“C” in Figure 4) serves as a single point
anchor for a single user attachment. Minimum breaking strength is 3,600 lbs (16kN).
Conforms to EN795:2012 Type A, OSHA 1926.502, 1910.140, AS/NZS 5532.
System W1 6116635 7 Used on standard wood poles with 1/2” (12mm) fasteners.
System CE1 6116636 8 To extend the system up to 48” (1.2m) beyond a nishing platform. Additional feature (“A”
in Figure 8) serves as a single point anchor for a single user attachment. Minimum breaking
strength is 16kN (3,600 lbs). Conforms to EN795:2012 Type A, OSHA 1926.502, 1910.140,
AS/NZS 5532.
CE1 System will t rung types and spacing listed below.
System T1
(ANSI/OSHA Certied Only)
6116618 9 Used on standard rung attachments. Telescoping tube will extend single point anchor to
30” (0.76m). Additional feature (“A” in Figure 9) serves as a single point anchor for a single
user attachment. Minimum breaking strength is 3,600 lbs (16kN). Conforms to OSHA
1926.502 and 1910.140.
T1 System will t rung types and spacing listed below.
Tensioner 10 After groove pulls through plate, cable is in tension.
Cable Install 11 Conrm that the large pin is resting inside of the top plate.
Cable Guide 12 Used to guide the cable in vertical systems.
Stando Bracket 5 Used in conjunction with the M1 and M2 system to provide an attachment for a safety
system or cable guide.
Lad-Saf X2 13, 14
Used as a Sleeve in vertical systems. Allows the user to move freely up and down the
system while maintaining attachment. Use only with supplied karabiner or snaphook.
Lad-Saf X3 15
Lad-Saf X3+ 16, 17
System Tag 18
System Tag Markings and RFID Tag
1 Installation Date 7 Date Inspected
2 Installed By 8 System serial number
3 Anchorage Requirements 9 System warnings
4 Max Users Per System 10 Cable type and sleeve compatibility matrix along
with standards certication.
5 System Length 11 RFID Tag
6 Date of Manufacture
Single Point Anchor Warning 19 Stamping on Washer, top of Systems L1, L2, L3, CE1 and T1. Stamping on Monopole Single
Point Anchor Assembly (“C” in Figure 4) used with Systems M1 and M2.
1 Standard to which Anchor conforms. 4
Used for fall arrest.
2 Maximum number of users. 5
Do not use for lifting.
3 Read user instruction. 6
Manufacturer internet site.
Rung Supports 20 Used to provide additional support for rung types that are unable to withstand loading
requirements as specied in Section 2.2.
Spacing 9"-12.25" (200mm-310mm)
Cylindrical rung 0.5"-1.6" (13mm-40mm) diameter
Square rung 0.5"-1.6" (13mm-40mm)
Diamond rung 0.5"-1.6" (13mm-40mm) height
Angle Iron 0.5"-1.6" (13mm-40mm) leg height
Rectangular rung 0.5"-1.6" (13mm-40mm) height, 0.5"-1.9" (13mm-48mm) width
EN
