3M X90w - Web Remote Control

42
Open browser when it is possible to communicate with projector. Corresponding
browser is Internet Explorer 5.5 or later.
Specify http://(projector IP address)/ to start.
For example, http://192.168.1.10/
(Input this URL when IP address is not changed.)
After start up, enter your ID and password, and click [Logon]. Following window
appears as shown in g. 2.6.a.
You can use your Web browser to remote control the projector once the projector
is properly congured and connected to your PC via the wireless LAN card or via
wired LAN.
2.6 Utilize Web Remote Control
• Do not attempt to control the projector with the projector's remote
control and via your Web browser at the same time. Attempt to do so may
causes a projector operational error.
NOTE
Fig. 2.6.a Utility selection window for Web Remote Control
2. Equipment connection and network setting
