3xLogic VISIX Gen III Series - Getting Started and Basic Operation; Adding Cameras to VIGIL Server

Pg. 4
OSD Menu Tree
MOTION
SETUP
EXIT
PRIVACY
MOTION OFF / ON
DET WINDOW
DET TONE 0 ~ 4
MDRECT FILL OFF / ON
SENSITIVITY 0 ~ 10
MOTION OSD OFF / ON
TEXT ALARM OFF / ON
SIGNAL OUT OFF / ON
EXIT JUMP
COMMUNICA
CAM TITLE
OFF / RIGHT UP / LEFT
DOWN
IMAGE RANGE FULL / COMP / USER
FREQ 50Hz / 60Hz
LANGUAGE
ENG / CHN / CHN(S) /
JPN / KOR
INITIAL OFF / ON
EXIT JUMP
TRANS
0 ~ 3
EXIT JUMP
SAVE & EXT
EXIT
PRIVACY OFF / ON
ZONE NUM 0 ~ 15
ZONE DISP OFF / ON
H-POS 0 ~ 59
V-POS 0 ~ 33
H-SIZE 0 ~ 60
V-SIZE 0 ~ 34
Y LEVEL 0 ~ 20
CB LEVEL 0 ~ 20
CR LEVEL 0 ~ 20
MOTI
PRIV
S ET
EXIT
