3xLogic VISIX Gen III Series Menu Guide

Pg. 5Pg. 4
Exposure Settings
1
LENS
MANUAL : Manual mode supports the fixed board lens or the manual iris lens.
AUTO : AUTO mode sets the camera’s iris automatically.
Under the LENS sub-menu, you can adjust the following settings :
1. LEVEL
Change the camera's iris value manually. If AUTO is selected, this option is disabled.
2. BRIGHTNESS
Adjust the camera’s brightness from 0~20. The higher the number, the brighter the image
will appear.
3. SHUTTER
Set the shutter speed to AUTO, Manual, or FLC (Flicker-less mode).
* If AUTO is selected, select from the following options :
- NORMAL : Set when the camera is installed in an indoor environment.
- DEBLUR : Set when the camera is installed in an outdoor environment.
* Select FLC if the camera is experiencing some flickering in the image.
The shutter speed will be set to 1/100 for NTSC, or 1/120 for PAL.
* If Manual is selected, set the shutter speed from the options :
- 1/30(1/25) ~ 1/30000.
EXPOSURE
LENS
LENS
BACKLIGHT
DRC
DEFOG
AGC
SENS-UP
3D DNR
EXIT JUMP
LEVEL
BRIGHTNESS
SHUTTER
2-MOTOR
RETURN
AUTO
OFF
OFF
OFF
10
X4
HIGH
20
10
AUTO
1
EXPO MOTI PRIVRGB D&N FUNC SET EXIT
