DIP switch setting
Rated capacity
range
Reference battery type (example)
1
2
3
4
0
0
0
0
10 – 19,5 Ah Powersonic PS-12120 F1
0
0
0
1
20 – 34,5 Ah
Powersonic PS-12260 B
0
0
1
0
35 – 49,5 Ah Powersonic PS-12380 B
0
0
1
1
50 - 55 Ah
Powersonic PS-12550 B
After changing a battery setting you should reboot the charger board. Press the RESET button on the
charger board
Why is it important? The power supply equipment of the Compact 500 implements a very precise voltage-
and current-controlled charger with additional temperature compensation. It also keeps the battery under
constant surveillance, including measurement of internal battery resistance in the order of milliohms, with
accuracy within 1 mΩ. The battery capacity setting is necessary to cover a whole range of different battery
sizes and provide optimal charging parameters.
