6.9.2. Local network (L-Net)
L-Net works as a daisy-chain bus between the Compact 500 main unit and remote network devices, such
as paging consoles. It is dedicated to provide a powered bus to peripheral devices. Every L-Net port is
powered with 24V DC and power over L-Net is always enabled.
L-Net capacity of single a Compact 500 unit is limited to the following figures:
Maximum 8 devices per port,
Maximum 16 devices per Compact 500 main unit.
L-Net daisy chain topology
For more information about installation of remote network devices, please go to the network device
installation manual.
