4EVAC Compact 500 - Cable and Connection Specifications

Hacousto Holland bv
Industrieweg 87
2651BC Berkel & Rodenrijs
4EVAC Compact 500 quick guide
DoP OD 16.47
Author:
DD
Design revision:
2.0
Page 30 of 33
8. Connections and recommended cable types
How
many
Connector
type
Signal type
Additional
information
Recommended cable
(minimum)
Max. length
Analog audio in
2
pluggable
screw
terminal
block
5.08 mm
Analog
balanced
mono audio,
0dBu
n/a
Balanced shielded
microphone cable, typ. 2
x 0.25mm
2
100m
EVAC / SILENCE /
RESET in
8
Pull-down
input with fault
detection
(open/short)
EOL resistors 10kΩ
+ 4.7kΩ in series
Depends on length, typ.
N x 0.75~1.5mm2 (N –
number of individual
triggering signals from /
to fire detection system)
1000m
EVAC / FAULT/
RESET out
3
Potential-free
relay output
n/a
1000m
GPI
8
Pull-down
input
n/a
Depends on length, typ.
N x 0.75~1.5mm2 (N –
number of individual
triggering signals from /
to external devices)
1000m
GPO
8
Open collector
output
n/a
1000m
Loudspeaker line
6
100V audio
100Hz – 12kHz
passive EOL
module for 20kHz
line monitoring
Depends on length and
load, typ. 2 x
0.75~1.5mm
2
1000m
G-Net port
2
RJ-45
Full duplex RS-
422
Redundant ring
with power
delivery
FTP CAT5e
250m
(to next
device)
L-Net port
3
Daisy chain with
power delivery
250m
(total length)
Mains
1
screw
terminal
110-230V AC
50/60Hz
n/a
3 x 1.5mm
2
50m
Battery
1
screw
terminal
24V DC
optimal for spade
(fork) cable
termination
1 x 4 mm
2
1 m
(total length)
