Every amplifier channel corresponds to the loudspeaker line as follows:
AMP 0
AMP 1
AMP 2
AMP 3
A
B
A
B
A
B
Backup amplifier Line 1 Line 2 Line 3 Line 4 Line 5 Line 6
Amplifier slots
0 1 2 3
