4EVAC Compact 500 - Technical Specifications

Hacousto Holland bv
Industrieweg 87
2651BC Berkel & Rodenrijs
4EVAC Compact 500 quick guide
DoP OD 16.47
Author:
DD
Design revision:
2.0
Page 31 of 33
9. Technical specifications
Standalone system
Number of zones
max. 6 local zones
Maximum total loudspeaker load
600 W RMS (420W RMS pure sinewave according to EN54-16)
Power amplifiers
6 x 100 W, modular (2 channels per module), bridgeable up to 3 x 200 W
Standby power amplifiers
2 x 100 W / 1 x 200 W dedicated backup amplifiers
Loudspeaker line monitoring
Built-in
20kHz AC monitoring with EOL module, short/open/impedance deviation
Loopdrive
loop DC monitoring with short-circuit isolators, short/open/earth leakage, EN54-
17 certified
Loudspeaker type
with 100V step-down transformer
Voice messages
Storage
max. 16 audio files x 1 minute each, micro-SD card with content monitoring
Message player
Max. 2 simultaneous local message playback
Controls and indications
General controls / indications
Lamp test button, silence button, power, evac, general fault LED indicators
Fault indications
Power supply, system fault, network, zone fault
Zone controls / indications
6 x configurable zone selection button, zone EVAC/FAULT/BUSY LED indicators
Evac manual control
EVAC message, ALERT message, SILENCE, RESET, fireman mic with PTT button
Fireman microphone
Integrated Fireman Mic with priority and electrical monitoring
Power supply equipment
Built-in power supply system, EN 54-4 certified.
AC supply
110 – 230 V AC, 50/60Hz
AC current consumption
max. 5.3A @115V AC / 2.65A @230V AC
Inrush current
20A @115V AC, 40A @230V AC
Power supply protection
Overload current limiting, over voltage shutdown, over temperature shutdown.
Battery requirements
Type
Sealed, rechargeable lead-acid battery for stationary use
Capacity
10 – 55 Ah
Charging time (80% capacity)
< 24 h
Rated voltage
24 V DC (2 x 12V)
Battery dimensions
2 batteries, each of max. 230 x 138 x 207 mm (LxWxH)
Battery weight
max. total 32.6 kg
Inputs
2 x BGM
2 x independent balanced analogue in, line-level mono, 22kΩ input impedance
6x EVAC in, 1x SILENCE in, 1x RESET in
monitored logic inputs, 4.7kΩ +10kΩ EOL resistors
8 x GPI
unmonitored logic inputs (pull-down, configurable active low/hi)
Outputs
EVAC out, FAULT out
Potential-free relay output (configurable NO/NC)
GPO
8 x Open collector output (configurable NO/NC)
Loudspeaker out
6 x 100V transformer output, 20 kHz AC monitoring with EOL
Amplifiers
Type
Class D
Protection
over load shutdown, over temperature shutdown
Backup amplifiers
2 dedicated backup channels, auto backup at end stage failure, auto restore
Efficiency
80% @ rated power
