4EVAC Compact 500 - Page 32

Hacousto Holland bv
Industrieweg 87
2651BC Berkel & Rodenrijs
4EVAC Compact 500 quick guide
DoP OD 16.47
Author:
DD
Design revision:
2.0
Page 32 of 33
All information provided in this document is subject to change without notice. 4EVAC may also make improvements and/or changes
in the products described in this information at any time without notice.
Output voltage
max. 100V RMS
Rated power
100W per channel, 200W bridged
Output bandwidth
50 Hz – 20 kHz
SNR
>80 dB
THD + N
0.1% @ rated power
Audio
Frequency response
Local BGM
50 Hz – 20 kHz
Messages, network streaming
100 Hz – 12 kHz
Analog input- output latency
< 10 ms (stand-alone system)
Network audio stream format
24 kHz sampling, ADPCM compressed
Message file input format
24 kHz, 16 bit, mono WAV
DSP features
HP/LP filter, multipoint parametric EQ, delay
Mechanical
Dimensions (HxWxD)
80 x 52 x 28 cm
Weight (full config, without batteries)
29 kg
Housing material
Steel / ABS
IP rating
IP 30
Mounting
Wall-mounted box
Network system
Max. number of devices in the network
255
Max. number of zones
255
Max. total system output power
102 kW
Number of simultaneous network audio channels
2
Network audio transmission latency
0.3 ms per device
Local network
Architecture
Master-slave, up to 16 slave devices per C500 main unit
Connection
3 x L-Net port, RJ-45, powered daisy chain, digital audio & control data
Cabling
X-over FTP CAT5e (or higher)
Current consumption
max. 500 mA (up to 8 slave devices) per L-Net port,
Max. length of local bus
default
250 m
with twisted-pair extender
500 m
Global network
Architecture
Peer-to-peer, up to 255 C500 main units
Connection
2 x G-Net port, RJ-45, powered redundant ring, digital audio & control data
Cabling
X-over FTP CAT5e (or higher) / multimode optical fiber
Current consumption
max. 500 mA per port, reserved only for network extenders
Max. distance between devices
default
250 m
with copper extenders
750 m
with fiber extenders
2500 m
