A.O. Smith BMS Interface User Manual

42
Instruction manual - BMS Interface
5.4 Solar codes
Internal code
Display
error code
Description
43
C02
Internal error control
44
F06
Ionisation error
45
C02
Internal error control
47
S01
Bottom tank sensor open
50
S04
Flue gas sensor 1 open
52
S05
Flue gas sensor 2 open
53
S02
Top tank sensor 1 open
54
S03
Top tank sensor 2 open
63
S11
Bottom tank sensor shorted
66
S14
Flue gas sensor 1 shorted
68
S15
Flue gas sensor 2 shorted
69
S12
Top tank sensor 1 shorted
70
S13
Top tank sensor 2 shorted
79
C03
Reset error
80
C04
Selection error
82
F19
Supply voltage error
255
-
No error
Internal code
Display
error code
Description
0
C05
Internal error control
1
C05
Internal error control
2
C05
Internal error control
3
C05
Internal error control
5
S07
Solar circuit sensor open
6
S06
Storage tank sensor open
9
S08
Collector sensor open
13
S17
Solar circuit sensor shorted
14
S16
Storage tank sensor shorted
17
S18
Collector sensor shorted
20
F18
Communication error
255
-
No error
