A.O. Smith BMS Interface User Manual

Instruction manual - BMS Interface
43
6 Status
6.1 Introduction
6.2 Control water heater
6.3 Solar control
Via the BMS Interface, the state of the water heater and the solar control can be read out
separately. The actual state of the control of the water heater can be found on parameter
7. When a solar control is present, its state can be viewed on parameter 22.
The numbers that will be read out refer to certain states of the control(s). Some states
shall appear and disappear so quickly that they won’t be visible. This is no problem.
In the table beneath, the reference to the numbers is specified:
Code
Description
0
Resetting the control
1
Resetting the control
2
Standby, no active burner cycle
3
Pre purge of the fan / unit
4
Pre purge of the fan / unit
5
Pre purge of the fan / unit
6
Check safety devices
7
Check safety devices
8
Ignition of the gas mixture
9
Ignition of the gas mixture
10
Burning is started, unit is heating up
11
Stop signal for burner cycle
12
Stop signal for burner cycle
13
Post purge of the fan / unit
14
Post purge of the fan / unit
15
Error present
16
Error present
17
Internal check of the control
18
Internal check of the control
19
Internal check of the control
20
Internal check of the control
21
Waiting time between states
Code
Description
0
Resetting the solar control
1
Resetting the solar control
2
Standby, no active solar cycle
3
Solar pump started, unit is heating up
4
Error present
5
Waiting time between states
