A.O. Smith CENTURY E-PLUS - Wire Selection Guide

16
115V Power Line
Maximum Distance from Fuse Box to Motor
Motor Hp 50’ 100’ 150’ 200’
1
⁄
3
14 14 12 12
1
⁄
2
14 12 10 10
3
⁄
4
12 12 10 8
1 12 10 8 8
1-
1
⁄
2
10 10 8 6
2 10 8 66
3 ————
230V Power Line
Maximum Distance from Fuse Box to Motor
Motor Hp 50’ 100’ 150’ 200’
1
⁄
3
14 14 14 14
1
⁄
2
14 14 14 14
3
⁄
4
14 14 14 14
1 14 14 14 12
1-
1
⁄
2
14 14 12 12
2 14 14 12 10
3 12 12 10 10
THE SIZES SHOWN IN THE FOLLOWING WIRE SELECTION
CHARTS ARE RECOMMENDATIONS ONLY. ALWAYS FOLLOW
LOCAL AND NATIONAL ELECTRIC CODES.
Guides for copper conductors only.
WIRE SELECTION GUIDE
