A.O. Smith CENTURY E-PLUS - Centurion Switchless (Easy Connect)

For motors manufactured in/after Nov., 1991 (Serial #BJ11)
Dual Voltage Type CX-
1
⁄
2
to 1
1
⁄
2
Hp
230/115 Volt Switchless
29
ORNG
LINE 1 LINE 2
L2 L1
B A
BRN
RED
WHT
BLK/YLW
YELLOW
ORNG
BRN
1
3
2
PROTECTOR
MAIN
CAPACITOR
WHT
BLK/YLW
LINE 1
LINE 2
L2 L1
1/2 PHASE
1/2 PHASE
A
BLK
YELLOW
BLK
RED
BLUE
B
HIGH VOLTAGE LOW VOLTAGE
Wiring Diagram #16635902. Connection Label #17536715.
CENTURION
®
/SE/II
