A.O. Smith CENTURY E-PLUS - Page 52

51

L.S. MAIN
H.S. MAIN
START
CAPACITOR
RUN
CAPACITOR
RED
RED
RED
ORNG
YLW
YLW
ORNG
YLW-BLK
BLK
BLK
BLK
L. S. PHASE
II.S. PHASE
BLU
BLU
PROTECTOR
WHT
WHT
BRN
YLW-BLK
SPLICE TYP.
2 PLACES
HIGH SPEED
LOW SPEED
LI
L2
1
2
3
2
3
6
5
4
Two-Speed
Single Voltage
115 or 230 Volt
Type CXSM 1
1
⁄
2
/.18 HP
Type CXSM 2.0/.25 HP
through 4.5/.50 Spl HP
INTERNAL WIRING EXTERNAL CONNECTIONS
Wiring Diagram #179859.
FLEX 48
®
FRAME
