A.O. Smith Cyclone XL 100 Series User Manual

7
8
1
4
2
3
7
5
9
11
10
6
Figure 4. Combustion Blower & Burner Assembly
34. Heat shield & insulation
35. Burner ange gasket
36. Observation sight glass
37. Burner
38. Flame rod
39. Flame rod gasket
40. Blower discharge gasket
41. Burner gasket
42. Spark rod
43. Spark rod gasket
44. Ignition cable
4 3 2
1
Figure 5. Burner Blower Assembly
1. Gas Valve
2. Air Intake Adapter
3. Venturi
4. Blower

A.O. Smith Cyclone XL 100 Series Specifications

General

Brand	A.O. Smith
Model	Cyclone XL 100 Series
Category	Water Heater
Language	English
