8
TOP VIEW
2
3
4
3
5
6
7
3
8
9
1
Figure 6. Top View
1. Burner/Blower Assembly
2. Blocked Intake Air switch
3. Powered anode rods
4. Temperature-Pressure Relief Valve
5. 2” NPT hot water outlet connection
6. Temperature Probe
7. Spark Ignition Control
8. 120 VAC junction box
9. Exhaust/Condensate Elbow
