18
Owner’s manual
Smart MMI
Display control * Monochrome
Display diagonal size,
resolution
2.4 inches, 240 X 320 pixels
Dimensions sMMI without dock 53 mm x 85 mm x 14 mm (W
X L X H)
Connectivity Micro-B 1.1 USB, 5-volt power
supply, 500 mA connection
to PC, incl. diagnostic and
parameterisation software
Mechanical/electrical
contacting
Twist-to-lock, corrosion-proof
contacts, spring loaded
Lighting LED Backlight, 70 – 350 cd/
m²
Display plate Scratchproof, quenched and
tempered acrylic glass plate
Weight sMMI (detached) 55 g
5.1.6 Technical data
Drive
Range* Up to 120 km
Speed 25 km/h
Rated power (peak) 250 watts (650 watts)
Operating voltage 36 volts
Rated torque 12 Nm
Peak torque 40 Nm
Efficiency 80% (incl. electronics)
Control Power electronics Integrated in wheel hub
Cassette receiver Cassette receiver commercially
available plug-in cassette, incl.
9-fold transmission
Brake disk Diameter from 160 mm
Intake torque Variable torque support can be
adjusted to dropout
Weight 4.36 Kg (just drive, incl. plugs
and cable, without brake disk,
freewheel, cassette)
