32
Owner’s manual
5.3.2.11 Display of information and
warnings
The battery's remaining capacity is shown
in field [11] as a standard. Depending on
the travelling situation, information and
warnings can also be indicated in the field
as shown below.
Display of battery's capacity
(standard representation)
The battery's remaining
capacity is shown stepwise by
a decreasing white bar.
Charging process of the
battery
1. The battery charger is
plugged in and the battery
is being charged (only for battery
models which are charged via a second
charging socket which is why the power
connection from the battery to the sMMI
does not have to be disconnected).
2. The battery is charged by energy fed by
the motor (recuperation, see also section
3.2.5).
Warning
The battery is flat. No power
can be taken from the battery,
motorised assistance of the Pedelec is no
longer available. Please charge the battery
as soon as possible using the supplied
charger.
Braking assistant active
During a downhill tour, your
Pedelec is automatically braked
within the preset limits (see section 3.2.6)
Service reminder
The service interval of your
Pedelec has expired. Please
arrange a service appointment
with your specialist dealer. The display can
be reset by your dealer using diagnostic
software.
Warning - Temperature problem
In case of extremely long and steep
inclines (especially in BOOST
mode), the drive generates
heat leading to an automatic reduction
of performance inside the motor from a
temperature of +80°C. This is shown on the
display by the temperature warning signal.
Thanks to the intelligent multipoint thermal
management monitoring (see also section
4), the motor will never be overheated. The
performance is reduced to such an extent
that any damage is excluded. Very rarely
(e.g. heating by external heat sources) the
system can be switched off completely until
temperatures return to within the range of
permissible operating values again.
