2.5 List of Connectors
The board has a number of connectors that allow you to configure your
system to suit your application. The table below shows the function of
each board's connectors:
Connectors
Label Function
CN1 USB 2.0 Port 1 Connector
CN2 USB 2.0 Port 2 Connector
CN3 Primary IDE Hard Drive Connector
CN4 Digital I/O Connector
CN5 Front Panel
CN6 Serial Port COM 2 Connector
CN7 Parallel Port 1 Connector
CN8 Dual Channel LVDS Connector
CN9 4P Power Connector
CN12 Audio Input/Output Connector
CN13 Ethernet 10/100 Base-TX RJ-45 Phone Jack
CN14 External 5VSB/PWRGD Connector
CN15 IrDA Connector
CN16 Fan Connector
CN17 Mini-DIN PS/2 Connector
CN18 Serial Port COM 1 Connector
CN19 CRT Display Connector
