SubCompact Board GENE-8310
Chapter 2 Quick Installation Guide 2-16
11 TXL1# 12 TXL1
13 TXL2# 14 TXL2
15 TXL3# 16 TXL3
17 LVDS_DATA 18 LVDS_CLK
19 TXU0# 20 TXU0
21 TXU1# 22 TXU1
23 TXU2# 24 TXU2
25 TXU3# 26 TXU3
27 LCD Volt. 28 Ground
29 TXUCLK# 30 TXUCLK
2.19 4P Power Connector (CN9)
Pin Signal
1 +12 Volt.
2 Ground
3 Ground
4 +5 Volt.
2.20 Audio Input/Output Connector (CN12)
Pin Signal Pin Signal
1 MIC_IN 2 MIC_Vcc
3 Audio Ground 4 CD_GND
5 LINE_IN L 6 CD_L
7 LINE_IN R 8 CD_GND
9 Audio Ground 10 CD_R
11 LINE_OUT L 12 LINE_OUT R
13 Audio Ground 14 Audio Ground
To Next Page
