SubCompact Board GENE-8310
Chapter 2 Quick Installation Guide 2-19
5 VGA Ground 13 CRT_HSYNC
6 VGA Ground 14 CRT_VSYNC
7 VGA Ground 15 CRT_SCL
8 VGA Ground
2.28 External Battery (VBAT2)
Pin Signal
1 VBAT (+3 Volt.)
2 Ground
2.29 Mini PCI Slot (MPCI1)
Standard Specification.
2.30 CompactFlash Disk Slot (CFD1)
Pin Signal Pin Signal
1 Ground 26 Ground
2 SDD3 27 SDD3
3 SDD4 28 SDD4
4 SDD5 29 SDD5
5 SDD6 30 SDD6
6 SDD7 31 SDD7
7 SDCS#1 32 SDCS#1
8 Ground 33 Ground
9 Ground 34 Ground
10 Ground 35 Ground
11 Ground 36 Ground
12 Ground 37 Ground
13 +5 Volt. 38 +5 Volt.
