SubCompact Board GENE-8310
Chapter 2 Quick Installation Guide 2-18
2.24 Fan Connector (CN16)
Pin Signal
1 FAN Sense
2 +5 Volt.
3 Ground
2.25 Mini-DIN PS/2 Connector (CN17)
Pin Signal Pin Signal
1 Keyboard Data 2 Mouse Data
3 Ground 4 Shield
5 +5 Volt. 6 Keyboard Clock
7 Shield 8 Mouse Clock
2.26 Serial Port COM1 Connector (CN18)
Pin Signal Pin Signal
1 DCDA
2
RXA
3 TXA
4
DTRA
5 Ground
6
DSRA
7 RTSA
8
CTSA
9 RIA
10
N/C
2.27 CRT Display Connector (CN19)
Pin Signal Pin Signal
1 CRT_RED 9 5 Volt.
2 CRT_GREEN 10 VGA Ground
3 CRT_BLUE 11 N/C
4 N/C 12 CRT_SDA
