Aaeon GENE-8310 - Front Panel (CN5); Serial Port COM2 Connector (CN6)

SubCompact Board GENE-8310
Chapter 2 Quick Installation Guide 2-14
2.15 Front Panel (CN5)
Pin Signal
1-2 ATX Power-on Button
3-4 HDD Active LED
5-6 External Speaker
7-8 Power LED
9-10 System Reset Button
2.16 Serial Port COM2 Connector (CN6)
COM2/ RS-232 Mode
Pin Signal Pin Signal
1 DCDB 2 RXB
3 TXB 4 DTRB
5 Ground 6 DSRB
7 RTSB 8 CTSB
9 RIB 10 N/C
COM2/ RS-422 Mode
Pin Signal Pin Signal
1 TXD- 2 RXD+
3 TXD+ 4 RXD-
5 Ground 6 N/C
7 N/C 8 N/C
9 N/C 10 N/C
COM2/ RS-485 Mode
Pin Signal Pin Signal
1 TXD- 2 N/C
3 TXD+ 4 N/C
