22
12. SPECIFICATIONS
12-1. Specifications
MODEL
FG-30KAM
FG-30KBM
FG-60KAM
FG-60KBM
FG-150KAM
FG-150KBM
FG-60KAL FG-150KAL
Weight capacity
(kg)
30 60 150 60 150
0.01 0.02 0.05 0.02 0.05
0.005 * 0.01 * 0.02 * 0.01 * 0.02 *
Min. display
(kg)
0.002 0.005 0.01 0.005 0.01
Weight capacity
(lb)
60 150 300 150 300
0.02 0.05 0.1 0.05 0.1
0.01 * 0.02 * 0.05 * 0.02 * 0.05 *
Min. display
(lb)
0.005 0.01 0.02 0.01 0.02
Weight capacity
(oz)
960 2400 4800 2400 4800
0.5 1 2 1 2
0.2 * 0.5 * 1 * 0.5 * 1 *
Min. display
(oz)
0.1 0.2 0.5 0.2 0.5
No. of samples
5 (can be changed to 10, 20, 50 or 100) pieces
Max. counts
120,000 pcs 96,000 pcs 120,000 pcs 96,000 pcs 120,000 pcs
Min. unit weight
0.25 g 0.625 g 1.25 g 0.625 g 1.25 g
Repeatability
(Std. deviation)
0.005 kg 0.01 kg 0.02 kg 0.01 kg 0.02 kg
Linearity error
±0.01 kg ±0.02 kg ±0.05 kg ±0.02 kg ±0.05 kg
Sensitivity drift
±20 ppm / °C (10°C~30°C / 50°F~86°F)
Display
7 segment LCD display (Character height 26 mm)
Display update
10 times per second
Operating temp.
-10°C~40°C / 14°F~104°F, less than 85% R.H. (non-condensing)
Power supply
AC adapter or C size (R14P / LR14) x 4 batteries
Battery operating
Approximately 150 hours with alkaline dry cell battery
Weighing pan
size
300 x 380 mm / 11.8 x 15.0 in.
390 x 530 mm
15.4 x 20.9 in.
Dimension
FG-KAM: 300(W) x 624(D) x 781(H) mm
11.8(W) x 24.6(D) x 30.7(H) in.
FG-KBM: 380(W) x 464(D) x 118(H) mm
15.0(W) x 18.3(D) x 4.6(H) in.
390(W) x 771(D) x 781(H) mm
15.4(W) x 30.4(D) x 30.7(H) in.
Weight
(approximately)
FG-KAM: 11.2 kg
FG-KBM: 9.7 kg
16.4 kg
Calibration weight
(Factory setting)
30 kg
60 lb
60 kg
150 lb
150 kg
300 lb
60 kg
150 lb
150 kg
300 lb
*) Factory setting
